Nokia 9500 MPR - Figure 295 Select Spare Core-E Equipment Type

WebEML User Manual Enable equipment
479
Figure 295 Select spare Core-E equipment type
4. Click Apply.
The spare Core-E card will populate slot #2. See Figure 296.
Protection informations updating window opens.
5. Click OK.
6. Verify port segregation provisioning. Port segregation should be provisioned
between the Core Ethernet ports and other Ethernet and/or radio ports where
connectivity is not desirable. See Provision port segregation/connectivity for
detailed steps to view/provision port segregation.
Release 7.0.0 3DB 19286 ACAA Issue 01
