Nokia 9500 MPR - Figure 752 Release Switch Core-E

WebEML User Manual Perform protection switching
1007
Figure 752 Release Switch Core-E
To perform a Forced EPS Switch on the Main card
1. Select Protection Schemes/Slot#/Equipment Protection/Main#1 in the
resource tree area. Figure 753.
2. On the Commands tab, from the New Value drop-down menu, select Forced.
3. Click Apply.
The Switch confirmation window displays.
4. Click OK.
Caution: Forced EPS switching equipment will cause a hit to traffic.
Release 7.0.0 3DB 19286 ACAA Issue 01
