Provision port segregation/connectivity
398
WebEML User Manual
45.3 Procedure
1. Select Segregated Ports Icon. See Figure 227.
Figure 227 Segregated Ports icon
The Segregated Ports window opens. See Figure 228.
Figure 228 Segregated Ports window
2. Port Segregation
When parallel radio paths exist between two MSS shelves, port segregation
should be provisioned between the parallel radio paths at both ends to prevent
a loss of traffic.
3. Double-click on the port icon to provision the port connectivity.
Port window displays. See Figure 229 and Figure 230.
Release 7.0.0 3DB 19286 ACAA Issue 01
