Provision protection scheme parameters
768
WebEML User Manual
Figure 580 Equipment Protection Scheme Parameter tab
2. Select Equipment Protection in the resource tree area.
3. From the Restoration Criteria partition, verify restoration criteria selection and
provision if required:
a. Select restoration criteria radio button, Not Revertive or Revertive.
b. Click Apply.
To provision the Hot StandBy Protection Schemes parameter
1. Select Protection Schemes/HSB Protection in the resource tree area.
The HSB Protection Scheme Parameters tab displays in the main window. See
Figure 581.
Note: For 1+1 HSB/SD protection type, EPS restoration criteria is always dimmed. The
restoration criteria selected for HSB protection is applied to EPS automatically.
Release 7.0.0 3DB 19286 ACAA Issue 01
