Nokia 9500 MPR - Figure 233 Auxiliary Cross Connections Menu

Configure AUX cross connections (ETSI market
only)
404
WebEML User Manual
• To create an AUX Cross connection
• To delete an AUX Cross connection
To create an AUX Cross connection
1. Select in the New Cross-Connection area the first Termination Point (this can
be a local service channel or a service channel in a radio link). Note: the local
service channel must be first enabled in the AUX unit setting menu.
2. Select the second Termination Point as shown in the example in Figure 233.
Figure 233 Auxiliary Cross Connections menu
3. Click on Add. The new cross-connection will appear in the list (upper part of the
screen as shown in Figure 234).
Note: The cross-connections are bi-directional.
Note: The Apply button has not been implemented.
Release 7.0.0 3DB 19286 ACAA Issue 01
