Provision equipment port
440
WebEML User Manual
4. Click Apply.
The SFP port will populate the selected port #. See Figure 260.
Figure 260 Provisioned P8ETH SFP port
5. Verify port segregation provisioning. Port segregation should be provisioned
between the SFP Ethernet port and other Ethernet and/or radio ports where
connectivity is not desired. See Provision port segregation/connectivity for
detailed steps to view/provision port segregation.
To provision MSS-O SFP port
1. Select the MSS/CORE slot in the resource tree area. The selected name will
highlight in blue.
2. Click the Settings Tab in the resource detail area.
3. From the Port # 4 Usage drop-down menu, select port usage type SFP.
Note: Ports 1-4 and ports selected SFP are ready for provisioning.
Release 7.0.0 3DB 19286 ACAA Issue 01
