Nokia 9500 MPR - Figure 109 ETH OAM Window

Configure EFM OAM
214
WebEML User Manual
The ETH OAM window opens. See Figure 109.
Figure 109 ETH OAM window
2. Choose the Ethernet interface from the list.
3. Choose the Active or Passive radio button in the Link OAM Mode field.
4. In the Link OAM Parameter pane, choose the Enable radio button in the Link
OAM field.
5. Click on the Apply button. The link is enabled.
To disable an OAM link
1. In the ETH OAM Configuration window, select the interface from the list.
2. In the Link OAM Parameter pane, choose the Disable radio button in the Link
OAM field.
