WebEML User Manual Perform protection switching
1015
Figure 760 Manual HSB Switch: Spare Radio Channel to Main Radio Channel
To perform a Lockout on the HSB Spare Radio Channel
1. Select Protection Schemes/Slot#/HSB Protection/Spare#0 in the resource
tree area. See Figure 761.
2. On the Commands tab, select Lockout in the New Value drop-down menu.
3. Click Apply.
The Switch confirmation window displays.
4. Click OK.
