Nokia 9500 MPR - Figure 619 MPT-HLC Additional Settings Tab

Configure radio parameters
822
WebEML User Manual
Figure 619 MPT-HLC Additional Settings tab
55. Provision MPT-HLC radio link identifier:
i. Select Link Identifier Configuration Enabled check box.
ii. Enter the Expected Identifier value (0 to 255).
iii. Enter the Sent Identifier value (0 to 255).
iv. Click Apply.
56. Provision the MPT-HLC Synchronization Status Messaging
Open the appropriate radio main view depending on your radio configuration
and select the Additional Settings tab; see Figure 619.
Note: If the MPT-HLC is part of a LAG, you cannot change the SSM or PPP settings on an
individual radio. Go to Administer L1/L2 radio and L2 Ethernet LAG ports to administer LAG
ports.
Release 7.0.0 3DB 19286 ACAA Issue 01
