WebEML User Manual Configure radio parameters
823
57. Provision MPT-HLC radio channel Synchronization SSM:
i. Select the Synchronization SSM Enabled check box.
ii. Click Apply.
58. Provision the MPT-HLC Point to Point Protocol settings
Open the appropriate radio main view depending on your radio configuration
and select the Additional Settings tab; see Figure 619.
i. Provision MPT-HLC radio channel PPP:
ii. From the PPP RF panel, select the Enabled check box.
iii. Select the Routing IP Protocol: (OSPF or None).
iv. If OSPF is selected, then select OSPF Area: (0 to 4).
v. Click Apply.
59. Provision the PKT throughput booster setting
Open the appropriate radio main view and select the Additional Settings tab; see
Figure 619.
60. Provision MPT-HLC radio PKT throughput booster:
See Figure 619 for the following steps:
i. From the Pkt Throughput Booster panel, select the Enabled check box.
ii. Click Apply.
61. Administer the MPT-HLC Alarm Profile settings
Open the appropriate radio main view and click on the Additional Settings tab;
see Figure 619.
Note: If the MPT-HLC is part of a LAG, you cannot change the SSM or PPP settings on an
individual radio. Go to Administer L1/L2 radio and L2 Ethernet LAG ports to administer LAG
ports.
Note: OSPF Area must be provisioned prior to provisioning the PPP RF channel.
Release 7.0.0 3DB 19286 ACAA Issue 01
