View alarms
256
WebEML User Manual
5. Click Done to save the filter. Click Cancel to close Add Filter window and
discard all selections.
Figure 143 shows an example of a timed filter for major transmission alarms for
slot 5 direction 1 alarms only.
To delete Alarm Manager filters
1. From the Alarm Manager Main Menu Bar, select Filters>Delete Filters.
The Delete Filters window opens. See Figure 144.
Figure 144 Alarm Manager Delete Filters window
2. From the scope pane, select one or more NEs to delete their filters.
3. From the Filters pane, select one or more filters to delete.
4. Click Done to delete the filters. Click Cancel to close Delete Filters window and
discard all selections.
