Nokia 9500 MPR - Figure 614 MPT-HLC Settings Tab for Fixed Modulation

WebEML User Manual Configure radio parameters
813
28. Select an action.
a. To Provision the MPT-HLC radio for fixed modulation, go to step 29.
b. To Provision the MPT-HLC radio for adaptive modulation, go to step 32.
29. Provision the MPT-HLC radio for fixed modulation
Open the appropriate radio main view depending on your radio configuration
and select the Settings tab; see Figure 614.
Figure 614 MPT-HLC Settings tab for fixed modulation
30. Provision MPT-HLC radio port:
i. In the Mode field, select the Preset button.
Note: Depending on the modem profile selected, the Tx power may become out of range.
If this occurs, provision the Tx power to the desired level or to one supported by the modem
profile to clear the warning message.
