Configure radio parameters
814
WebEML User Manual
ii. Click on the Data Help button under the Mode field. The Data Help window
opens.
iii. In the Data Help window, double-click on the table row for the desired
channel spacing, modulation scheme, and option.
iv. Click on the Data Help button in the Shifter panel. The Data Help window
opens.
v. In the Data Help window, double-click on the table row for the desired shifter
value.
vi. When the MPT-HLC is connected to the MSS shelf, the Channel #1
TxFreq(KHz) field is automatically populated. If the MPT-HLC is not
connected, enter the TX RF Frequency within the allowed range.
vii. If the MPT-HLC is not connected, enter the Rx RF Frequency within the
allowed range.
viii. Enter the MPT-HLC radio channel User Label, if applicable.
ix. Click Apply.
31. Select an action.
a. To Provision the MPT-HLC radio for fixed modulation, go to step 36.
b. To Provision the MPT-HLC manual transmit power level (RTPC), go to
step 42.
c. To Provision the MPT-HLC Automatic Transmit Power Control (ATPC), go
to step 44.
32. Provision the MPT-HLC radio for adaptive modulation
Note: The Channel #1 Rx Freq (KHz) field displays the Rx RF Frequency and is the result
of the following calculation: RX Frequency = TX Frequency - Shifter Frequency
Note: In a Protected MPT-HLC configuration, the Main and Protect MPT-HLC cards use the
same CT screen. The parameters on the Spare (Channel #0) part of the screen are the
same as the Main (Channel #1) part of the screen. Most Channel #0 fields will be
automatically populated to match Channel #1, except the transmit power. The transmit
power must be configured independently.
Note: The Reference Modulation should be set to a value lower than or equal to 256 QAM.
The Reference Modulation should also be equal to the Minimum modulation.
Release 7.0.0 3DB 19286 ACAA Issue 01
