WebEML User Manual Administer network configuration
139
Figure 48 IP Static Routing Configuration window (IPv4)
2. Select desired Host or Network Address Choice radio button: Host or Network.
3. Which IP Static Routing Configuration was selected?
a. If Network, enter the IP Mask of the radio in the IP Mask text field..
b. If Host, enter the IP Address of the radio in the IP Address text field
4. Select desired Default Gateway or Point to Point I/F Choice radio button:
Default Gateway IP Address or Point To Point Interface Index.
5. Which Default Gateway or Point to Point I/F Choice was selected?
a. If Default Gateway IP Address, enter the Default Gateway IP Address in
the Default Gateway IP Address text field.
b. If Point To Point Interface Index, from the Interface Type drop-down menu,
select Gateway.
6. Click Create.
Release 7.0.0 3DB 19286 ACAA Issue 01
