Provision cross connections in a mixed fiber/
microwave Ring
662
WebEML User Manual
Figure 475 Node A (protected) to Node D (protected): PDH-Ring cross-connection on Node D
a. Choose the flow IDs to cross-connect from the Available VLANs list
b. Choose the Service profile: TDM2TDM or TDM2ETH
c. Choose the Clock Source, if the Service profile is TDM2ETH
d. Enter the Ring Destination MAC address: Node A Multicast MAC address
To provision a cross-connection between Node A and Node C
1. Both traffic end points belong to the fiber chain; see Figure 476.
