Nokia 9500 MPR - Figure 211 Ring to Ring Cross Connection

WebEML User Manual Provision cross connections
381
Figure 211 Ring to Ring Cross Connection
2. On the RING-RING pop-up, select ERP Instance to be cross connected.
3. On the RING-RING pop-up, select Flow ID number in the Available VLANs field.
4. From the Service Profile drop-down menu, select TDM2TDM or TDM2ETH.
5. Is the Profile configured with TDM2ETH?
a. If yes, go to step 6.
b. If no, go to step 7.
6. From the Clock Source drop-down menu, select ADAPTIVE or DIFFERENTIAL.
7. On the RING-RING pop-up, click >>.
Note: Ranging is supported for RADIO-RADIO cross-connection entry.
Release 7.0.0 3DB 19286 ACAA Issue 01
