WebEML User Manual Administer network configuration
135
Figure 45 TMN Ethernet interface: Settings tab
6. Select action.
a. To Provision TMN Ethernet interface, go to step 7.
b. To Deprovision TMN Ethernet interface, go to step 14.
7. Provision TMN Ethernet interface
See Figure 45 for the following steps:
Select TMN Working Mode Enabled check box (checked).
8. Enter TMN IP Address in IP Address field for the NMS interface (MGMT Port on
Core card).
9. Enter IP Mask or Netmask in IP Mask field.
Release 7.0.0 3DB 19286 ACAA Issue 01
