Administer network configuration
136
WebEML User Manual
10. Select IP Routing Protocol from drop-down menu: Static Routing or OSPF.
11. If the OSPF IP Routing Protocol is selected, from the OSPF Area Number
drop-down menu, select OSPF Area Number (0 - 3).?
12. Click Apply.
13. Close CORE Main View window.
14. Deprovision TMN Ethernet interface
See Figure 45 for the following steps:
15. Click Apply.
16. Close CORE Main View window.
To administer Port#4 TMN Ethernet interface
1. Select MSS/Core-Main slot #1 in the resource tree area. The selected name
will highlight in blue. This selection also highlights the CORE-Main card in blue
on the graphical representation of the MSS-8 shelf in the resource list area.
2. Double-click on the blue Core-Main Card. See Figure 44.
CORE Main View Slot#1 displays.
3. Select TMN Interface tab.
4. Select Port#4 TMN Ethernet in the resource tree area.
5. Select Settings tab. See Figure 46.
Release 7.0.0 3DB 19286 ACAA Issue 01
