Nokia 9500 MPR - Figure 321 Resource List Area: MPTACC Selected

WebEML User Manual Enable equipment
505
Figure 321 Resource list area: MPTACC selected
3. From the Port # (1-4) Usage drop-down menu, select port usage type MPT-HC
or MPT-HQAM. See Figure 322.
Note: MPTACC Ports 1 and 2 support optical SFP interfaces. Ports 3 and 4 support
electrical GigE Ethernet Interfaces. Up to two ports are supported. Either one or two optical,
one or two electrical, or one electrical and one optical ports are supported simultaneously.
Note: MPTACC Ports 1 and 3 are not supported simultaneously. MPTACC Ports 2 and 4
are not supported simultaneously.
Release 7.0.0 3DB 19286 ACAA Issue 01
