Nokia 9500 MPR - Figure 216 Ethernet to Radio Cross Connection

WebEML User Manual Deprovision cross connections
387
RADIO-ETH pop-up displays. See Figure 216.
Figure 216 Ethernet to Radio cross connection
2. On the RADIO-ETH pop-up, select Flow ID check box (unchecked) for all cross
connects to be deprovisioned.
3. On the RADIO-ETH pop-up, click OK.
4. On the Cross Connection screen, click Apply.
To deprovision a Radio to Radio cross connection
1. Double-click on the Radio port to Radio port line.
RADIO-RADIO pop-up displays. See Figure 217.
Release 7.0.0 3DB 19286 ACAA Issue 01
