WebEML User Manual Download I&C parameter data
277
35 Download I&C parameter data
35.1 Purpose
This chapter provides the procedures to download Installation and Commissioning
(I&C) parameter data for the radio.
35.2 General
The I&C Parameters include the following:
• an NE Inventory file
• a .csv file for each MPT connected to the NE, showing the RSL information
The files can be loaded to the TRDS; see the 9500 MPR Turn-up Manual.
35.3 Procedures
This section provides the procedure to download the I&C parameters data.
To download I&C parameters data
1. From the main menu bar, select Diagnosis > I&C Parameters; see Figure 154.
Figure 154 I&C Parameters main menu bar path
A Save dialog box appears.
2. Choose a directory to save the files and click Save.
