WebEML User Manual Upgrade a Ring to R5.1.0 software
579
54 Upgrade a Ring to R5.1.0 software
54.1 Purpose
This chapter provides the procedure to activate R5.1.0 software on Ring nodes when
ERPS is in use. This procedure must be performed when upgrading from a release
earlier than R5.0.0 to ensure that the Ring status is maintained during the software
upgrade.
54.2 General
The first node on which the software is activated must be a neighbor to the RPL
owner. This procedure will use Node B as an example, as shown in Figure 388.
Figure 388 Ring example for upgrade
Release 7.0.0 3DB 19286 ACAA Issue 01
