Nokia 9500 MPR - Figure 311 P32 E1 DS1 Enabled

To Next Page

To Previous Page

WebEML User Manual Enable equipment

495

Figure 311 P32E1DS1 enabled

To enable a DS3 P2E3DS3 card

1. To enable a DS3 P2E3DS3 card

Select MSS-n/Slot# (slot 3 through 8) in the resource tree area where the

P2E3DS3 card will be enabled. The selected slot will highlight in blue. This

selection also highlights the selected slot in blue on the graphical representation

of the MSS shelf in the resource list area. See Figure 312.
