Nokia 9500 MPR - Figure 300 Select Slot to Enable Easv2

To Next Page

To Previous Page

Enable equipment

484

WebEML User Manual

Figure 300 Select slot to enable EASv2

2. Click the Settings Tab in the resource detail area.

3. From the Equipment Type drop-down menu, select EASv2. See Figure 301.

Release 7.0.0 3DB 19286 ACAA Issue 01
