Nokia 9500 MPR - Figure 485 Node a to Node C (Protected): PDH-Ring Cross-Connection on Node a

To Next Page

To Previous Page

Provision cross connections in a mixed fiber/

microwave Ring

670

WebEML User Manual

Figure 485 Node A to Node C (protected): PDH-Ring cross-connection on Node A

a. Choose the flow IDs to cross-connect from the Available VLANs list

b. Choose the Service profile: TDM2TDM or TDM2ETH

c. Choose the Clock Source, if the Service profile is TDM2ETH

d. Enter the Ring Destination MAC address: Node C Multicast MAC address

2. Configure a pass-through cross-connection on Node B, see Figure 486.

Release 7.0.0 3DB 19286 ACAA Issue 01
