WebEML User Manual Provision cross connections in a mixed fiber/
microwave Ring
681
Figure 496 Node B to Node C: pass-through cross-connection on Node D
a. Choose the flow IDs to cross-connect from the Available VLANs list
b. Choose the Service profile: TDM2TDM or TDM2ETH
c. Choose the Clock Source, if the Service profile is TDM2ETH
d. Enter the Ring Destination MAC address: Node C Unicast MAC address
e. Enter the Ring Source MAC address: Node B Unicast MAC address
6. Provision a cross-connection between NE E and Node D
One traffic end point is connected using Ethernet to the fiber chain, see
Figure 497.
Release 7.0.0 3DB 19286 ACAA Issue 01
