Provision cross connections in a mixed fiber/
microwave Ring
674
WebEML User Manual
Figure 489 Node A to Node C (protected): pass-through cross-connection on Node D
a. Choose the flow IDs to cross-connect from the Available VLANs list
b. Choose the Service profile: TDM2TDM or TDM2ETH
c. Choose the Clock Source, if the Service profile is TDM2ETH
d. Enter the Ring Destination MAC address: Node C Multicast MAC address
e. Enter the Ring Source MAC address: Node A Unicast MAC address
2. Provision a cross-connection between Node B and Node C
Both traffic end points belong to the fiber chain; see Figure 490.
