WebEML User Manual Disable equipment

549

Figure 363 Disable MPT-HC ODU

4. Click Apply.

The MPTACC port # will display Empty and the MPT ODU is removed from the

resource list area. See Figure 364.

Note: MPT ODU card will not disable if the port has any cross-connections associated with

the port.

Release 7.0.0 3DB 19286 ACAA Issue 01
