Nokia 9500 MPR - Figure 318 Select Slot to Enable MPTACC

To Next Page

To Previous Page

Enable equipment

502

WebEML User Manual

Figure 318 Select slot to enable MPTACC

2. Click the Settings Tab in the resource detail area.

3. From the Equipment Type drop-down menu, select MPTACC. See Figure 319.
