Nokia 9500 MPR - Procedures; Figure 42 Local Configuration Main Menu Bar Path

Administer network configuration
132
WebEML User Manual
18.3 Procedures
This section provides the following procedures:
• To provision NE IP address
• To administer TMN Ethernet interface
• To administer Port#4 TMN Ethernet interface
• To provision IP static routing in IPv4
• To provision IP static routing in IPv6
• To provision OSPF Area Configuration
• To activate the IPv6 stack
• To view IP routing information
To provision NE IP address
1. From the main menu bar, select Configuration>Network Configuration>
Local Configuration. See Figure 42.
Figure 42 Local Configuration main menu bar path
The Local Configuration window opens. See Figure 43.
Release 7.0.0 3DB 19286 ACAA Issue 01
