Provision cross connections
372
WebEML User Manual
4. From the Profile drop-down menu, select TDM2TDM or TDM2ETH.
5. Is the Profile configured with TDM2ETH?
a. If yes, go to step 6.
b. If no, go to step 7.
6. From the TDM Clock Source drop-down menu, select ADAPTIVE or
DIFFERENTIAL.
7. Enter the destination MAC address where the RADIO will be terminated in the
MAC Address field.
8. On the RADIO-ETH pop-up, click OK.
9. On the Cross Connection screen, click Apply.
10. From the Connections tab, verify the RADIO-ETH cross-connections were
entered correctly.
To provision Radio to Radio Cross Connection
1. Verify port segregation provisioning. Port segregation should be provisioned
between parallel radio paths at both ends when they exist on the NE. When
making a cross connection to one of parallel radio ports, port segregation should
also be provisioned between the radio port and all other parallel radio ports.
Additionally, port segregation should be provisioned between the radio ports and
other Ethernet and/or radio ports where connectivity is not desirable. See
Provision port segregation/connectivity for detailed steps to view/provision port
segregation.
Note: The first two digits of the destination MAC address for unprotected ports must be set
to ‘unicast’ or ‘00’. The first two digits of the destination MAC address for 1+1 protected and
L1 LAG ports must be set to ‘multicast’ or ‘01’. The first two digits of the destination MAC
address for all ERPS ring nodes must be set to ‘unicast’ or ‘00’
Caution: When parallel radio paths exist between two MSS shelves, port
segregation should be provisioned between the parallel radio paths at both ends
to prevent a loss of traffic.
