Provision equipment port
454
WebEML User Manual
c. From the Port Status, select Enabled check box (checked).
d. Click on the Apply button.
e. From the User Label field, enter the User Label, up to fifteen characters.
f. For optical SFP, From the Auto Laser Shutdown drop-down menu, select
Enabled, Disabled Forced On, or Disabled Forced Off.
g. From the J0 Configuration pane, from the Mode drop-down menu, select
Disabled, SixteenBytesFrame, or OneRepeatedByte.
h. For SixteenBytesFrame, or OneRepeatedByte, from the Expected
Receiving Value field, enter the expected J0 value.
i. Click on the Apply button.
j. Enter the unique Flow ID number (2-4080).
k. From the Buffer Depth drop-down menu, select Low or High.
l. From the TDM Clock Source drop-down menu, select Differential or Node
Timing.
m. From the Service Profile field, verify SDH2SDH.
n. Click on the Apply button.
The SDH Main View updates adding the provisioned OC-3 port to the resource
list area. See Figure 273 and Figure 274.
Note: If the port will be part of a cross-connection to a LAG, select High buffer
depth.
Release 7.0.0 3DB 19286 ACAA Issue 01
