Configure radio parameters
842
WebEML User Manual
45. Select an action.
a. To Provision the spare MPT-HLS ATPC, go to step 46.
b. To Provision the MPT-HLS radio protection scheme, go to step 48.
46. Provision the spare MPT-HLS ATPC
Open the appropriate radio main view depending on your radio configuration
and select the Settings tab; see Figure 630 for an example of the ATPC
parameters.
47. Provision Spare MPT-HLS radio channel ATPC:
i. Select the ATPC Enabled check box.
ii. Enter the Min-Max transmit power value range (dBm).
iii. Enter the Remote ATPC Rx Threshold.
iv. Click Apply.
48. Provision the MPT-HLS radio protection scheme
Open the appropriate radio main view depending on your radio configuration
and select Protection Schemes tab; see Figure 632.
Note: Revertive restoration criteria is the default value.
Release 7.0.0 3DB 19286 ACAA Issue 01
