WebEML User Manual Provision Ethernet Ring Protection (ERP)
573
To enable an ERP Instance
1. From the ERP Instance area, select ERP instance to enable. See Figure 385.
2. Select ERP Enabled check box (checked).
3. Click Apply.
4. Perform To enable an ERP Instance on all Ring Nodes. Repeat steps 1 through
3 to enable ERP Instance on all Ring Nodes.
5. Verify Port and Protection Statuses around the ring.
i. Verify East Port Current Status is Normal.
ii. Verify West Port Current Status is Normal.
iii. Verify RPL Owner/RPL Port status is Blocked.
iv. Verify all other East and West Port Forward Statuses are Unblocked.
v. Verify all Protection Statuses are Idle.
To add a PDH Flow to an ERP Instance
1. To add a PDH Flow to an ERP Instance
2. Add PDH flows to ERP Instance using the following procedure:
See Figure 386 for the following steps:
a. Select ERP instance to add PDH flows.
b. Enter PHD flow VLAN IDs in Add VLANS text field.
c. Click >>.
d. VLAN IDs are added to the VLAN ID table.
e. Click Apply.
Note: To provision an Ethernet Ring, it is recommended to Create Ring Topology and ERP
Instances on all ring nodes prior to enabling the ERP Instance. To provision additional
Ethernet ring nodes repeat steps 1 through 12 on each ring node.
Release 7.0.0 3DB 19286 ACAA Issue 01
