Configure radio parameters
840
WebEML User Manual
b. To Provision the MPT-HLS Automatic Transmit Power Control (ATPC), go
to step 43.
38. Provision the MPT-HLS manual transmit power level (RTPC)
Open the appropriate radio main view depending on your radio configuration
and select the Settings tab; see Figure 627.
39. Provision MPT-HLS radio channel transmit power level:
i. Choose the TxPower (dBm) level for the lowest modulation scheme in the
range. Power levels for the other modulation schemes will be set
automatically.
ii. Click Apply.
40. Select an action.
a. To Provision the spare MPT-HLS RTPC, go to step 41.
b. To Provision the MPT-HLS radio protection scheme, go to step 48.
41. Provision the spare MPT-HLS RTPC
Open the appropriate radio main view depending on your radio configuration
and select the Settings tab; see Figure 629.
42. Provision Spare MPT-HLS radio channel transmit power level:
i. Choose the TxPower (dBm) level for the lowest modulation scheme in the
range. Power levels for the other modulation schemes will be set
automatically.
ii. Click Apply.
43. Provision the MPT-HLS Automatic Transmit Power Control (ATPC)
Open the appropriate radio main view depending on your radio configuration
and select the Settings tab; see Figure 630.
Release 7.0.0 3DB 19286 ACAA Issue 01
