Configure radio parameters
802
WebEML User Manual
35. Provision the MPT-HL Point to Point Protocol settings
i. From the PPP RF panel, select the Enabled check box; see Figure 603.
ii. Select the Routing IP Protocol radio button: (OSPF or None).
iii. If OSPF is selected, then select OSPF Area: (0 to 4).
iv. Click Apply.
36. Provision the PKT throughput booster setting
See Figure 603 for the following steps:
i. From the Pkt Throughput Booster panel, select the Enabled check box.
ii. Click Apply.
37. Administer the MPT-HL Alarm Profile settings
See Figure 603 for the following steps:
a. In the Alarm Profile panel, click on the Alarm Severity Profile icon. The
Alarm Severity Profile window opens.
b. Choose an alarm severity profile. Click on the Show details button for more
information if needed.
c. Click Apply.
To provision the MPT-HLC transceiver
1. Select an action.
a. To Configure the MPT-HLC co-channel XPIC, go to step 2.
b. To Configure the MPT-HLC 1+1 XPIC, go to step 13.
c. To Configure the MPT-HLC radio protection type, go to step 24.
d. To Provision the MPT-HLC radio for fixed modulation, go to step 29.
e. To Provision the MPT-HLC radio for adaptive modulation, go to step 32.
f. To Provision the MPT-HLC 1+1 spare radio channel, go to step 35.
g. To Provision the MPT-HLC manual transmit power level (RTPC), go to
step 38.
h. To Provision the spare MPT-HLC RTPC, go to step 41.
Note: OSPF Area must be provisioned prior to provisioning the PPP RF channel.
Release 7.0.0 3DB 19286 ACAA Issue 01
