Configure radio parameters
816
WebEML User Manual
iv. In 1+1 HSB configurations, from the Driving MSE drop-down menu, choose
Lowest or Highest MSE.
v. In the Supported Modulation panel, choose all the modulation schemes to
be used by the adaptive modulation. The schemes must be contiguous.
vi. Click on the Data Help button in the Shifter panel. The MPT-HLC Shifter
Data Help window opens.
vii. In the Data Help window, double-click on the table row for the desired shifter
value.
viii. When the MPT-HLC is connected to the MSS shelf, the Channel #1
TxFreq(KHz) field is automatically populated. If the MPT-HLC is not
connected, enter the TX RF Frequency within the allowed range.
ix. If the MPT-HLC is not connected, enter the Rx RF Frequency within the
allowed range.
x. Enter the MPT-HLC radio channel User Label, if applicable.
xi. Click Apply.
34. Select an action.
a. To Provision the MPT-HLC 1+1 spare radio channel, go to step 35.
b. To Provision the MPT-HLC manual transmit power level (RTPC), go to
step 42.
c. To Provision the MPT-HLC Automatic Transmit Power Control (ATPC), go
to step 44.
35. Provision the MPT-HLC 1+1 spare radio channel
Open the appropriate radio main view depending on your radio configuration
and select the Settings tab; see Figure 616.
Note: The Channel #1 Rx Freq (KHz) field displays the Rx RF Frequency and is the result
of the following calculation:
RX Frequency = TX Frequency - Shifter Frequency
Note: In a Protected MPT-HLC configuration, the Main and Protect MPT-HLC cards use the
same CT screen. The parameters on the Spare (Channel #0) part of the screen is a mirror
image of the Main (Channel #1) part of the screen. Most Channel #0 fields will be
automatically populated to match Channel #1, except the transmit power. The transmit
power must be configured independently.
