WebEML User Manual Configure radio parameters
803
i. To Provision the MPT-HLC Automatic Transmit Power Control (ATPC), go
to step 43.
j. To Provision the spare MPT-HLC ATPC, go to step 47.
k. To Provision the MPT-HLC radio protection scheme, go to step 48.
l. To Provision the MPT-HLC link identifier, go to step 54.
m. To Provision the MPT-HLC Synchronization Status Messaging, go to
step 56.
n. To Provision the MPT-HLC Point to Point Protocol settings, go to step 58.
o. To Provision the PKT throughput booster setting, go to step 59.
p. To Administer the MPT-HLC Alarm Profile settings, go to step 61.
q. To Provision the MPT-HLC radio channel encryption, go to step 65.
r. To Administer the RX squelch settings, go to step 68.
s. To Configure the branching loss, go to step 71.
2. Configure the MPT-HLC co-channel XPIC
Open the appropriate radio main view and select the Settings tab; see
Figure 614.
3. Provision MPT-HLC 1+0 Horizontal XPIC Configuration:
i. Provision 1+0 Horizontal radio channel. See step 29 or 32 for detailed steps
to provision radio channel parameters.
ii. From the Option drop-down menu, choose gain configuration (Std/XPIC.
iii. Click Apply.
iv. Provision Horizontal radio channel XPIC Configuration Polarization to
Horizontal.
v. Click Apply.
4. Provision MPT-HLC 1+0 Vertical XPIC Configuration:
i. Provision 1+0 Vertical radio channel. Provision the Vertical radio channel
using the following radio parameters identical to the values provisioned for
the horizontal radio channel (step 3i).
• Mode
• Reference Channel Spacing
• Modulation
• Shifter
•TX Freq
•Rx Freq
