Administer In-Band TMN VLAN port
126
WebEML User Manual
4. Select Settings tab. See Figure 39.
5. Select the Working Mode Enabled check box.
6. Enter the VLAN ID for the In-band TMN Ethernet interface in the VLAN ID field.
7. Choose the DSCP value from the DSCP drop-down menu.
8. Choose the PCP value from the PCP drop-down menu.
9. Enter the IP address for the In-band TMN Ethernet interface in the IP address
field.
10. Enter Sub-Network Mask for the In-band TMN Ethernet interface in the IP Mask
field (IPv4 mode) or Network Prefix size in the Prefix Length field (IPv6 mode).
11. From the IP Routing Protocol drop-down menu, Static Routing or OSPF.
12. If OSPF is selected, from the OSPF Area Number drop-down menu, select
OSPF Area Number for the In-band TMN Ethernet interface.
13. Select all Ethernet ports which will be a member of TMN In-Band from the
Associated Ethernet Ports field.
14. Click Apply.
Configuration Update window displays.
15. Click OK.
16. Verify In-band TMN Ethernet interface provisioning. See Figure 40.
Release 7.0.0 3DB 19286 ACAA Issue 01
