WebEML User Manual Administer system date and time
167
Figure 79 NE Time Configuration window
2. Select Set NE Time with OS Time check box (checked).
3. Click Apply.
The Information ‘Set NE time success!’ window opens.
4. Click OK.
5. Click Close.
To provision NE Time to PC operating system time using Web Server
1. Log In to NE to view NE alarms. For detailed steps to log in to an NE using a
web browser, see Log in to and out of system.
The 9500MPR Web Server displays. Active Alarms is the default web server
window.
2. From the web server Main Menu pane, select Date & Time Setting.
The Date & Time Setting window displays. See Figure 80.
Release 7.0.0 3DB 19286 ACAA Issue 01
