WebEML User Manual Administer L1/L2 radio and L2 Ethernet LAG
ports
331
i. From the Configured LAGs pane, select the LAG to enable PTB.
ii. From the PTB pane, select the Enabled check box (checked).
iii. Click Apply.
To disable PTB for L1 radio LAG port
1. Using the LAG Configuration Tool Settings tab, disable PTB using the following
procedure: See Figure 181.
i. From the Configured LAGs pane, select the LAG to disable PTB.
ii. From the PTB pane, select the Enabled check box (unchecked).
iii. Click Apply.
To provision Wait-To-Restore (WTR) value
1. Using the LAG Configuration Tool Settings tab, provision WTR value using the
following procedure: See Figure 181.
a. From the Configured LAGs pane, select LAG to provision WTR value.
b. From the WTR drop-down menu, select WTR period (100 ms to 8 sec).
c. Click Apply.
Release 7.0.0 3DB 19286 ACAA Issue 01
