Provision cross connections
366
WebEML User Manual
5. On the PDH-ETH pop-up, click OK.
6. On the Cross Connection screen, click Apply.
7. From the Connections tab, verify the PDH-ETH cross-connection was entered
correctly.
To provision an SDH to Radio Cross connection
1. Verify port segregation provisioning. Port segregation should be provisioned
between parallel radio paths at both ends when they exist on the NE. Also port
segregation should be provisioned between the radio port and other Ethernet
and/or radio ports where connectivity is not desirable. See Provision port
segregation/connectivity for detailed steps to view/provision port segregation.
2. Select SDH port and drag to draw line to RADIO port.
SDH-RADIO pop-up displays. See Figure 201.
Caution: When parallel radio paths exist between two MSS shelves, port
segregation should be provisioned between the parallel radio paths at both ends
to prevent a loss of traffic.
Release 7.0.0 3DB 19286 ACAA Issue 01
