WebEML User Manual Provision cross connections
375
8. On the Cross Connection screen, click Apply.
9. From the Connections tab, verify the RADIO-RADIO cross-connections were
entered correctly.
To provision a PDH to Ring Cross Connection
1. Verify port segregation provisioning. Port segregation should be provisioned
between parallel radio paths at both ends when they exist on the NE. Also port
segregation should be provisioned between the radio port and other Ethernet
and/or radio ports where connectivity is not desirable. See Provision port
segregation/connectivity for detailed steps to view/provision port segregation.
2. Select a PDH port and drag to draw a line to the RING port.
PDH-RING pop-up displays. See Figure 208.
Caution: When parallel radio paths exist between two MSS shelves, port
segregation should be provisioned between the parallel radio paths at both ends
to prevent a loss of traffic.
Release 7.0.0 3DB 19286 ACAA Issue 01
