WebEML User Manual Configure radio parameters
831
• Mode
• Reference Channel Spacing
• Modulation
• Shifter
•TX Freq
•Rx Freq
iii. From the Option drop-down menu, choose gain configuration identical (Std/
XPIC) to the values provisioned for the horizontal radio channel (step 14
iii).
iv. Click Apply.
v. Provision Vertical radio channel XPIC Configuration Polarization to Vertical.
vi. Click Apply.
16. Open XPIC Configuration tool.
XPIC Configuration tool displays.
17. Select Horizontal Radio port and drag to draw line to Vertical RADIO port.
XPIC Association pop-up displays. See Figure 624.
Release 7.0.0 3DB 19286 ACAA Issue 01
