viii. Enter the MPT ODU radio channel User Label, if applicable.
ix. Click Apply.
To provision the radio for adaptive modulation using data help
1. Open the appropriate radio main view depending on your radio configuration
and select the Settings tab; see Figure 650.
2. Provision MPT ODU radio port:
i. In the Mode field, choose the Adaptive radio button.
ii. Click on the Data Help button under the Mode field. The 9500MPR MPT
ODU ACM Modem Profiles Data Help window opens.
Note: The Channel #1 Rx Freq (KHz) field displays the Rx RF Frequency and is the result
of the following calculation:
RX Frequency = TX Frequency - Shifter Frequency
Note: In a Protected MPT ODU configuration, the Main and Protect MPT ODU cards use
the same CT screen. The parameters on the Spare (Channel #0) part of the screen are the
same as the Main (Channel #1) part of the screen. Most Channel #0 fields will be
automatically populated to match Channel #1, except the transmit power. The transmit
power must be configured independently.
Note: For MPT-HC-HQAM/XP-HQAM, the Reference Modulation should be set to a value
lower than or equal to 256 QAM.
In the ANSI market for MPT-HC-HQAM/XP-HQAM, the Reference Modulation should also
be equal to the Minimum modulation.
Note: When communications have not been established with the radio, the radio
parameters may be provisioned using the data help. The following procedure is written
based upon MPT ODUs. The other radio types can be provisioned using a similar
procedure.
