WebEML User Manual Use the Provisioning Tool
897
6. Click on the Next button. The MPT configuration screen opens.
To configure the MPT Configuration screen
1. Configure the following parameters as needed:
− User Label
− SSM checkbox
− PPP RF in band management: choose OSPF or Static Routing
− RPS Configuration: In a protection configuration, select the Physical Cable
check box if a physical RPS cable is in use
− Revertive Restoration Criteria: enable the checkbox for revertive restoration
in a protection configuration.
− XPIC: in the Polarization field select the polarization to be used by the radio
channel (Vertical or Horizontal). The configuration will be completed on the
XPIC configuration screen.
Release 7.0.0 3DB 19286 ACAA Issue 01
