WebEML User Manual Use the Provisioning Tool
907
Enter an ID in the One-Shot Tributaries Configuration to provide the ECID
for port #1. The tool will number the other tributaries consecutively from the
number entered.
− TDM Clock Source: Adaptive or Differential.
− Line Length
− Line Coding
2. Configure the parameters that apply to all ports:
− AIS Insertion for LOF detection on DS1: select Enabled or Disabled. This
setting is applied to all DS1 modules according to the value of the field for
the module with the highest slot value: it is not applied on a per tributary
basis.
− Restoration Criteria: for 1+1 EPS are fixed to “Not Revertive” and cannot be
changed.
3. Click on the Next button. The next screen to open depends on the configuration.
To configure the P32E1DS1 unit configuration screen for the ETSI market
1. Figure 680 shows the E1 configuration screen.
Release 7.0.0 3DB 19286 ACAA Issue 01
