Core Facing PDH/SDH Tributary Loopback

960

WebEML User Manual

6. Select Not Active radio-button in the Activation area.

7. Click Apply.

Core Facing PDH/SDH Tributary Loopback is deactivated (Not Active). For PDH

loopback, see Figure 718. For SDH loopback, see Figure 719.
