Open and run performance monitoring
986
WebEML User Manual
To run PM on an L1 radio LAG port
1. From the resource tree area, select the Ethernet Statistics pane.
2. From the Ethernet Statistics pane, select the L1 radio LAG to on which to run
radio Ethernet PM.
3. To configure the Ethernet counters for an L1 radio LAG with EASv2, choose
TDM+ETHERNET or ETHERNET from the Aggregation Type drop-down menu
in the Configuration panel. Figure 737 shows the configuration.
Note: Measured throughput on an L1 LAG includes both TDM2TDM/TDM2ETH/
SDH2SDH data flow and Ethernet traffic.
Release 7.0.0 3DB 19286 ACAA Issue 01
