77 Perform Tx Diversity Antenna operations
77.1 Purpose
This chapter provides the procedures to perform transmit antenna diversity
operations in Web Server. Transmit Diversity Antenna is only available in the ANSI
market, with MPT-HLC in 1+1 HSB configuration.
The Tx Diversity Antenna (TDA) webpage displays a list of configured 1+1 HSB radio
directions with MPT-HLC.
The Tx Diversity Antenna webpage allows you to enable or disable TDA, view TDA
status, and perform manual force operations.
77.2 Procedures
This section provides the procedures to perform Tx Diversity Antenna operations.
1. From the Administration menu, select Tx Diversity Antenna.
The Tx Diversity Antenna webpage appears; see Figure 781.
Note: All MPT-HLC 1+1 HSB radio directions are displayed on the Tx Diversity
Antenna webpage, however, the TDA feature is operational only if the radio is
equipped with the dual relay switch assembly and connected to a diversity
antenna.
